Applications

These cables find wide application in measurement, control and supervision in process instruments and equipments, various communication and data acquisition systems, computer systems, digital control & measurement systems etc. and are designed to transmit signal without interference.

instruments and equipments

computer systems

digital control

data acquisition systems

Types & Sizes

• Typically in pair / traid formation (upto 50 Pairs, Triads) from 0.50 sq.mm to 2.50 sq.mm
  with screening for voltage grade upto 1.1 KV

Specification

Generally confirming to IS:1554 (Pt-1), BS: 5308 (Pt-1 & 2), IEC: 189 (Pt 1 & 2), IEC: 60227, VDE: 0815 & 0816, BS EN: 50288-7 and
designed to meet customer requirements.

Key Features

• Cables can be customised to meet customer requirements as per various national & international standards.

• Provides protection from induced voltage and allows to transmit signal at very low voltages to control processes and critical equipment.

Product Range

Fire survival cables improves safety, reduces fire damages to buildings or equipments and provides extra time to escape during fire.

Conductor

Copper – Solid, Stranded (Circular) or Flexible – Bare or Tinned

Insulation

PVC- GP/HR/FR/FRLS, PE, XLPE, Zero Halogen or EPR Rubber

Inner Sheath

PVC – GP/HR/FR/FRLS, PE, Zero Halogen or Rubber – FR/HOFR

Screening

Individual & Overall or Overall screening – Polyester Tape, Aluminium Mylar Tape, with Copper Drain Wire, Copper Tape or Tinned Copper Braiding

Armour

Galvanized Steel Round Wire / Flat Strip / Tape or GI / Tinned Copper Braiding

Outer Sheath

PVC – GP/HR/FR/FRLS, PE, Zero Halogen or Rubber- FR/HOFR/TRS
