Applications

Designed to maintain circuit integrity during fire and ensure maximum time for evacuation in case of emergency. Typically used in:

fire alarm

emergency lighting

critical circuits

other safety equipment

Types & Sizes

• Single core up to 1000 sq. mm and multicore up to 400 sq. mm

Specification

BS: 7846 or equivalent BS: 6387 Category CWZ, IEC: 60331 and designed to meet customer’s requirements.

Key Features

• Cables withstand 650° C for 3 hours (Category A), 750° C for 3 hours (Category B), 950° C for 3 hours (Category C)
  with resistance to fire with water and mechanical shock (Category CWZ).

• High resistance to fire & toxic gases with low emission.

• Ease and low cost of installation.

• Customization options available.

Product Range

Fire survival cables improves safety, reduces fire damages to buildings or equipments and provides extra time to escape during fire.

Conductor

Solid, Stranded (Sector/Circular) or Copper – Solid, Stranded (Sector/Circular) or Flexible – Bare or Tinned

Fire Barrier

Layers of Glass Mica Tape over Conductor & Insulation as per requirement.

Insulation

PVC, XLPE, EPR Rubber with Additional taping or screening if required

Inner Sheath

PVC – FR/FRLS, PE, Zero Halogen or Rubber – FR/HOFR.

Armour

Galvanised Steel Wire / Strip or Braided with Fibre Glass Tape (if required)

Outer Sheath

PVC – FR/FRLS, PE, Zero Halogen or Rubber – FR/HOFR.
